Product Details
This TQ midget front steering arm is a redesign of the Lafler / Dimension Designs steering arm used with beam axle front ends on three quarter midgets.
It is machined from aluminum with no lightening pockets, so nothing is removed from the load path. A steering arm takes every curb hit and every wheel-to-wheel shove that comes through the front end, and this one is built to keep its geometry instead of tweaking.
- Material: aluminum
- Width: 2.25 in tapering to 1.40 in
- Length: 4.75 in
- Thickness: 0.50 in
- Threads: 3/8-16
- Tie rod hole: 7/16 in
- Weight: .44 lbs
Fits TQ midgets running a beam axle front end. These arms are used as both right and left with no difference between sides, and should give 100% Ackermann. The arm mounts to our TQ Midget Beam Axle Front Spindle, which is sold separately. Sold individually.
